Description
| F-POE-G2 | |
|---|---|
| Dimensions | 196.4 x 93.5 x 32.4 mm ( 7.73 x 3.68 x 1.28″) |
| Weight | 288 g (10.2 oz) |
| Enclosure | White Polycarbonate |
| Interface Connections | (1) 1 Gbps SFP Port (1) DC Terminal Block (1) DC RJ45 Port DC Injection (1) 1000 Mbps Ethernet PoE Port 10/100 Mbps Ethernet not supported |
| Typical Power Consumption | 1.5W |
| Power Method | DC Terminal Block, 2-Wire, 24VDC or 50VDC DC In RJ45 Port, 2-Pair (4, 5+; 7, 😎 (24VDC Input), or 4-Pair (24VDC or 50VDC Input) Passthrough PoE RJ45 Port, 2-Pair (4, 5+; 7, 😎 (24VDC Input), or 4-Pair (24VDC or 50VDC Input) PoE Passthrough |
| PoE Output | PoE RJ45 Port, 2-Pair (4, 5+; 7, 😎 (24VDC), or 4-Pair (24VDC or 50VDC) PoE |
| DC Output | Terminal Block, 2-Wire (24VDC or 50VDC) |
| Input DC Voltage | 16 to 57V |
| Surge Protection | Built-In High-Current Gas Discharge Tube for DC Terminal Block and PoE Port |
| LED | White: Power On Blue: Connected Blue (Flashing): Activity |
| Operating Temperature | -40 to 60° C (-40 to 140° F) May be further restricted by the operating temperature range of the SFP module being used. |
| Operating Humidity | 10 to 95% Noncondensing |
| ESD/EMP Protection | ± 24kV Contact / Air for Ethernet |
| Certifications | CE, FCC, IC |
